BeagleBone Black System
Reference Manual
Page 48 of 108
6.2 Sitara XAM3359AZCZ100 Processor
The board is designed to use either the Sitara AM3358AZCZ100 or XAM3358BZCZ100
processor in the 15 x 15 package. The initial units built will use the XAM3359AZCZ100
processor from TI. This is the same processor as used on the original BeagleBone except
for a different revision. Later, we will switch to the AM3358BZCZ100 device when
released.
6.2.1 Description
Figure 29 is a high level block diagram of the processor. For more information on the
processor, go to http://www.ti.com/product/am3359.
Figure 29. Sitara XAM3359AZCZ Block Diagram
