BeagleBone Black System
Reference Manual
Page 74 of 108
7.3 USB Client
The USB Client connector is accessible on the bottom side of the board under the row of
four LEDs as shown in Figure 46. It uses a 5 pin miniUSB cable, the same as is used on
the original BeagleBone. The cable is provided with the board. The cable can also be
used to power the board.
Figure 46. USB Client Connector
This port is a USB Client only interface and is intended for connection to a PC.
