BeagleBone Black System
Reference Manual
Page 69 of 108
7.1.1 Connector P8
Table 10 shows the pinout of the P8 expansion header. Other signals can be connected to
this connector based on setting the pin mux on the processor, but this is the default
settings on power up. The SW is responsible for setting the default function of each pin.
There are some signals that have not been listed here. Refer to the processor
documentation for more information on these pins and detailed descriptions of all of the
pins listed. In some cases there may not be enough signals to complete a group of signals
that may be required to implement a total interface.
The PROC column is the pin number on the processor.
The PIN column is the pin number on the expansion header.
The MODE columns are the mode setting for each pin. Setting each mode to align with
the mode column will give that function on that pin.
