BeagleBone Black System
Reference Manual
Page 78 of 108
7.6 HDMI
Access to the HDMI interface is through the HDMI connector that is located on the
bottom side of the board as shown in Figure 50 below.
Figure 50. HDMI Connector
The connector is microHDMI connector. This was done due to the space limitations we
had in finding a place to fit the connector. It requires a microHDMI to HDMI cable as
shown in Figure 37 below. The cable can be purchased from several different sources.
Figure 51. HDMI Connector
