7.8 Ethernet
The board comes with a single 10/100 Ethernet interface located next to the power jack
as shown in Figure 53.
Figure 53. Ethernet Connector
The PHY supports AutoMDX which means either a straight or a swap cable can be used.
10/100
Ethernet
