106
Setting the limit positions using the operator control
1. Setting the limit positions
using the programming unit
Auto install (only for
articulated-arm awnings)
Run the shading solution in the
Extend direction until it passes
the Extend limit position and the
fabric is resting on the articulat-
ed arms
.
Then run the shading solution
without stopping in the Retract
direction until it stops automati-
cally at the upper stop
.
Lower point to upper stop
Run the shading solution to the de-
sired Extend limit position .
Then
run the shading solution without
stopping in the Retract direction
until it stops automatically at the
upper stop .
2. Deleting the limit positions
using the operator control
Run the drive for 6 seconds in the UP
or DOWN direction.
Then rapidly run through steps
to
of the deletion sequence shown
opposite until the drive clicks twice.
Short! Short! Short! Short!
Short! Short! Short! Press
and
hold!
SE+ K5 mute drives
Nonstop
