Configuration
EP31xx 99Version: 2.4
Index (hex) Name Flags Default value
1C00:02 SubIndex 002 RO 0x02 (2
dec
)
1C00:03 SubIndex 003 RO 0x03 (3
dec
)
1C00:04 SubIndex 004 RO 0x04 (4
dec
)
1C12:0 [}132]
Subindex RxPDO assign RW 0x00 (0
dec
)
1C13:0 [}132]
Subindex TxPDO assign RW 0x04 (4
dec
)
1C13:01 SubIndex 001 RW 0x1A00 (6656
dec
)
1C13:02 SubIndex 002 RW 0x1A02 (6658
dec
)
1C13:03 SubIndex 003 RW 0x1A04 (6660
dec
)
1C13:04 SubIndex 004 RW 0x1A06 (6662
dec
)
1C33:0 [}134]
Subindex SM output parameter RO 0x20 (32
dec
)
1C33:01 Sync mode RW 0x0022 (34
dec
)
1C33:02 Cycle time RW 0x000F4240 (1000000
dec
)
1C33:03 Shift time RO 0x00001388 (5000
dec
)
1C33:04 Sync modes supported RO 0xC00B (49163
dec
)
1C33:05 Minimum cycle time RO 0x0003D090 (250000
dec
)
1C33:06 Calc and copy time RO 0x00001388 (5000
dec
)
1C33:07 Minimum delay time RO 0x00000000 (0
dec
)
1C33:08 Command RW 0x0000 (0
dec
)
1C33:09 Maximum Delay time RO 0x00001388 (5000
dec
)
1C33:0B SM event missed counter RO 0x0000 (0
dec
)
1C33:0C Cycle exceeded counter RO 0x0000 (0
dec
)
1C33:0D Shift too short counter RO 0x0000 (0
dec
)
1C33:20 Sync error RO 0x00 (0
dec
)
6000:0 [}135]
Subindex AI inputs RO 0x11 (17
dec
)
6000:01 Underrange RO 0x00 (0
dec
)
6000:02 Overrange RO 0x00 (0
dec
)
6000:03 Limit 1 RO -
6000:05 Limit 2 RO -
6000:07 Error RO 0x00 (0
dec
)
6000:0E Sync error RO 0x00 (0
dec
)
6000:0F TxPDO State RO 0x00 (0
dec
)
6000:10 TxPDO Toggle RO 0x00 (0
dec
)
6000:11 Value RO 0x0000 (0
dec
)
6010:0 [}135]
Subindex AI inputs RO 0x11 (17
dec
)
6010:01 Underrange RO 0x00 (0
dec
)
6010:02 Overrange RO 0x00 (0
dec
)
6010:03 Limit 1 RO -
6010:05 Limit 2 RO -
6010:07 Error RO 0x00 (0
dec
)
6010:0F TxPDO State RO 0x00 (0
dec
)
6010:10 TxPDO Toggle RO 0x00 (0
dec
)
6010:11 Value RO 0x0000 (0
dec
)
6020:0 [}136]
Subindex AI inputs RO 0x11 (17
dec
)
6020:01 Underrange RO 0x00 (0
dec
)
6020:02 Overrange RO 0x00 (0
dec
)
6020:03 Limit 1 RO -
6020:05 Limit 2 RO -
6020:07 Error RO 0x00 (0
dec
)
6020:0E Sync error RO 0x00 (0
dec
)
6020:0F TxPDO State RO 0x00 (0
dec
)
6020:10 TxPDO Toggle RO 0x00 (0
dec
)
6020:11 Value RO 0x0000 (0
dec
)
6030:0 [}136]
Subindex AI inputs RO 0x11 (17
dec
)
6030:01 Underrange RO 0x00 (0
dec
)
6030:02 Overrange RO 0x00 (0
dec
)
6030:03 Limit 1 RO -
6030:05 Limit 2 RO -
6030:07 Error RO 0x00 (0
dec
)
