Speedometers Indicates the vehicle’s speed in
km/h or mph. To pass from one to the other,
press the “RESET” button.
Total/partial kilometre counter
The total kilometre counter shows the total
distance covered in kilometres.
Set in the mode instrumentation “TRIP A /
TRIP B” with the “SELECT” button.
The partial kilometre counter (TRIP A/TRIP B)
shows the distance covered since the last re-
set in kilometres.
The partial kilometre counter can be used to
estimate the possible distance to cover with a
full tank of fuel. This information may make it
possible to schedule future fuelling stops.
RESET/SELECT buttons
Buttons to set vehicle data.
Press the “SELECT” button to see the partial or
total kilometres.
When viewing partial kilometres (TRIP A/
TRIP B), it is possible to reset them by holding
down the ”RESET” button for 3 seconds.
Transmission gear display
The transmission gear display shows the se-
lected gear.
This model is equipped with 6 gears.
Anti-lock Brake System (ABS) warning light
1. ABS error: whenever any fault is detected
and saved, the ABS diagnostic light is on and
remains on also after repairing. The ABS dia-
gnostic light will turn o with the next SHUT-
DOWN/IGNITION of the instrument panel or
when the vehicle exceeds the speed of about
5 km/h.
2. Disabled ABS mode: the ABS diagnostic
light will ash once for about 1.30 seconds
(short ashing).
3. By keeping the ABS button pressed for a
time of 3/30 seconds, the ABS diagnostic light
will ash once for about 0.30 seconds (short
ashing).
4. ABS activated: When the instrument pa-
nel is on, the ABS diagnostic light will be on
until the vehicle reaches the speed of about 5
km/h. Once having exceeded this speed, the
diagnostic light will turn o.
WARNING
Usually the ABS diagnostic light stays on
when the instrument panel is switched on
and turns o when the vehicle speed is
above 5 km/h. Is the ABS diagnostic light
shows one of the following symptoms, one
or more faults may have been occurred on
the ABS system. In which event, take the
motorcycle to an authorized Benelli servi-
ce centre.
• The ABS diagnostic light does not go on
when the instrument panel is switched
on.
• The ABS diagnostic light will stay on
even when the vehicle exceeds the spe-
ed of about 5 km/h.
It is important to point out the fact that the
ABS is not active when the light is on, but the
braking system will continue working as a
normal system not equipped with ABS.
In this situation, a hard braking may lock the
wheels, causing slip and loss of stability of the
motorcycle.
