Turn signal indicator lights “ ” and
“ ”
Each indicator light will ash when its corre-
sponding turn signal lights are ashing.
Neutral indicator light “N”
This indicator light comes on when the tran-
smission is in the neutral position.
High beam indicator light “ ”
This indicator light comes on when the high
beam of the headlight is switched on.
Oil pressure warning light “ “
This light switches on when the engine oil
pressure is low.
It is possible to check the electrical circuit for
the light by turning the key to “ ”.
Once the engine is running, the light should
switch o.
If the light does not switch on when the key is
turned to “ ” or if the light stays on, get the
electrical circuit checked by an authorised Be-
nelli centre.
TIP
• Even if the oil level is sucient, the war-
ning light may icker when riding on a
slope or during sudden acceleration or
deceleration, but this is not a malfun-
ction.
• If a problem is detected in the oil level
detection circuit, the oil level warning
light will ash repeatedly. If this occurs,
have a Benelli dealer check the vehicle.
Engine trouble warning light “ ”
This warning light comes on if a problem is
detected in the engine or other vehicle con-
trol system. If this occurs, have a Benelli dealer
check the on-board diagnostic system.
The electrical circuit of the warning light can
be checked by turning the key to “
”.
The warning light should come on for a few
seconds, and then go o.
If the warning light does not come on initially
when the key is turned to “ ”, or if the war-
ning light remains on, have a Benelli dealer
check the vehicle.
Tachometer
The tachometer shows the running turnover
of the engine so that the rider can keep it wi-
thin the ideal power range.
Coolant temperature
This shows the temperature of the coolant.
The coolant temperature varies with changes
in the weather and engine load. if the “war-
ning lamp” ashes, stop the vehicle then stop
the engine and let it cool.
WARNING
Do not continue to operate the engine
if it is overheating.
Digital clock
Shows the time in hours and minutes.
Digital clock setting
Push and hold the menu switch “SELECT” for
3 seconds to enter the setting mode “TOTAL
KM”
Press and hold down the ”SELECT“ button for
3 seconds until the reading begins to lash.
Adjust the hour by pressing the“RESET” but-
ton.
Press the ”SELECT“ button to pass on to adjust
the minutes. Adjust the minutes by pressing
the ”RESET“ button.
Press the “SELECT” button again to quit.
Fuel gauge
The digital fuel gauge shows the capacity of
the fuel tank. As the fuel level drops, the lines
on the gauge will become closer and closer to
the “E” reserve area.
As soon as the inal line starts to lash, there is
an autonomy of about 3 litres of fuel.
Speedometer
Push and hold the menu switch “SELECT” for
3 seconds to enter the setting mode “TOTAL
KM”
