Benelli TRK 502 User Manual

3 - 18
Instrument and control functions
EN
3
Auxiliary USB jack
WARNING
To prevent electrical shock or short-circu-
iting, make sure that the cap is installed
when the auxiliary (USB) jack is not being
used.
NOTICE
The accessory connected to the auxiliary
USB jack should not be used with the en-
gine turned o, and the load must never
exceed 24 W (2A), otherwise the fuse may
blow or the battery may discharge.
This vehicle is equipped with an auxiliary USB
jack.
A 12-V accessory connected to the auxiliary
USB jack can be used when the key is in the
“ ” position and should only be used when
the engine is running.
To use the auxiliary USB jack
1. Turn the key to “ ”.
2. Remove the auxiliary USB jack cap.
3. Turn the accessory o.
4. Insert the accessory plug into the auxiliary
USB jack.
5. Turn the key to “
”, and then start the engi-
ne. (See page 5-1.)
6. Turn the accessory on.
1
1. Auxiliary USB jack cap
1. Auxiliary USB jack
1

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
