Benelli TRK 502 User Manual

EN
9
9 - 2
Consumer information
Model label
The label of the model is applied to the left
side of the steering head.
Record the information on this label in the
space provided. This information will be nee-
ded when ordering spare parts from a Benelli
dealer.
WARNING
Any changes to the ID number stamped on
the frame or engine will automatically ren-
der the warranty null and void.
Diagnostic connector
The diagnostic connector is located as shown.
Vehicle data recording
This model’s ECU stores certain vehicle data to
assist in the diagnosis of malfunctions and for
research and development purposes.
This data will be uploaded only when a spe-
cial Benelli diagnostic tool is attached to the
vehicle, such as when maintenance checks or
service procedures are performed.
Although the sensors and recorded data will
vary by model, the main data points are:
• Vehicle status and engine performance
data
• Fuel-injection and emission-related data
Benelli will not disclose this data to a third
party except:
• With the consent of the vehicle owner
• Where obligated by law
• For use by Benelli in litigation
• For general Benelli-conducted research
purposes when the data is not related to
an individual vehicle nor owner
Diagnostic Connector

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
