Benelli TRK 502 User Manual

Instrument and control functions
3 - 7
EN
3
ABS button
Do not try to adjust settings of ABS while the
motorcycle running. The ABS settings are
enabled when the vehicle speed is above 5
km/h.
Disabling ABS
Make sure the motorcycle is stationary and
in neutral. Keep the ABS button pressed for
3-5 seconds, the light will switch from steady
to ashing for about 1.30 seconds (short a-
shing). At this stage, the ABS system will be
not active and the braking system will conti-
nue working as a normal system not equip-
ped with ABS.
Enabling ABS:
Make sure the motorcycle is stationary and
in neutral. Keep the ABS button pressed for
3-5 seconds, the light will switch from steady
to ashing for about 1.30 seconds (short a-
shing). Another way for enabling the ABS sy-
stem is to switch o and then on again.
A: the procedure will be ignored by the sy-
stem if the ABS button was pressed for a time
ranging from 5 and 30 seconds.
The ABS will keep the current settings.
B: The ABS will be active again from any other
previous setting when the button is pressed
for a time longer than 30 secs.
ABS
~
ABS
~
ABS
~
ABS

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
