BenQ MP611 - YUV Alignment Procedure

102
Figure1
8. YUV Alignment Procedure
Equipment: -Pattern generator (VG-828) OSD Default value:
Item Value
Cal R Offset 127
Cal G Offset 127
Cal B Offset 127
Cal R Gain 127
Cal G Gain 127
Cal B Gain 127
YPbPr R Offset 122
YPbPr B Offset 122
AutoKeystone Cal
TiltRatio Flat 0
TiltRatio Flat 0
Procedure:
1 Connect power,YpbPr cable, into projector.
2. Change Timing and pattern of pattern generator:
Timing: 480i
Pattern: As Figure2
