Appendix 1 – Screw List /Torque
Model name :MP611 (MD)
Description Torque
Q'ty
No.
Screw P/N
Type Head
Length
Surface
(kgf-cm)
Where use
M2 1 8F.1A522.6R0
MACH PH
6 NI 2~3
FIXBLOCK==HOLDER
1
2 8F.HA722.5R0
TAP(DELTA
PH
5 NI
2~3
GEAR ==FIXBLOCK
1
BKT MB==LC
3
POWER==LC
2
LAMP BOX==LC
2
BALLAST==LC
3
3 8F.VA564.8R0
TAP(DELTA)
PH
8 NI 6~7
BLOWER==LC
2
UC==LC
4
4 8F.VA564.100
TAP(DELTA)
PH
10 NI 5~8
ENGINE==LC
3
MB==MB SHIELDING
5
MB BRACKET==ENGINE
1
5 8F.1G524.6R0
MACH PAN
6 NI 4~5
BKT BLOWER==NOZZLE
1
M3
6 8F.1A524.8R0
MACH PAN
8 NI 4~5
ASSY DOOR
2
#4-40
7 8F.00480.120 MACH HEX
8 NI 3~5 MB=REAR COVER
4
M4 8 8F.00010.161 MACH PAN
8 NI 6~7
GROUNDING==MB BKT
1
