Appendix E Electrical Specification
1. Timing Table
The Default timing is as following:
Resolution Mode
Refresh rate
(Hz)
H-frequency
(kHz)
Clock
(MHz)
720 x 400 720x400_70 70.087 31.469 28.3221
VGA_60 59.940 31.469 25.175
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
640 x 480
VGA_85 85.008 43.269 36.000
SVGA_60 60.317 37.879 40.000
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
800 x 600
SVGA_85 85.061 53.674 56.250
XGA_60 60.004 48.363 65.000
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
1024 x 768
XGA_85 84.997 68.667 94.500
1280 x 1024 SXGA3_60 60.020 63.981 108.000
1280 x 768 SXGA_60 60.09 47.77 80.768
1280 x 800 SXGA_60 59.96 49.65 83.458
YPbPr support timing is as following:
