1.3 Lamp Assembly.
i. Insert Lamp into Lamp Holder and make three datum contact with the lamp (Figure1-8)
ii. Hook “Clip_UP” on the Lamp Holder first. (Figure 1-9)
iii.Hook “Clip_DOWN” on the Lamp Holder second. (Figure 1-10)
iv. Check assembly again and make sure the three datum contact with the lamp.
v. Assemble Lamp Wire to Lamp
vi. Assemble “Lamp_Plate” on the Holder and fasten the screw (Figure 1-11)
