1.1 Gap (refer to C321 document)
ITEMS Specification
Cap between UC and LC；
step between UC and LC
Gap ≦ 0.5mm，step 0.3mm≦
Cap between Autio and RC Gap ≦ 0.5mm
Cap between UC and upper side of RC 0.2(+0.3/-0.2)mm
Cap between UC and both sides of RC 0.1(+0.3/-0.1)mm
Cap between Video and RC 0.85(+0.6/-0.6)mm
Cap between LC and RC 0.1(+0.3/-0.1)mm
Cap between USB and RC 0.5(+0.3/-0.3)mm
Cap between RC and D-sub out 1.2(+0.8/-0.8)mm
Cap between IR LENS and RC 0.15(+0.2/-0.1)mm
Cap between AC socket and RC 0.25(+0.25/-0.25)mm
Cap between RC and D-sub in 1.2(+0.8/-0.8)mm
Cap between FC and Ring-FC 0.1(+0.1/-0.05)mm
Cap between IR LENS and FC 0.15(+0.2/-0.1)mm
Cap between LENS and Ring-FC 1.5(+0.1/-0.1)mm
Cap between UC and FC 0.1(+0.3/-0.1)mm
Cap between PUSH-BTN and LC 0.3(+0.2/-0.2)mm
Step between FC and UC
0（+0.3/-0.3）mm
Cap between LED LENS and UC
0.1（+0.2/-0.1）mm
Cap between KEYFUN and UC
0.1（+0.2/-0.1）mm
Cap between Door and LC；
step between Door and LC
Gap ≦ 0.6mm，step 0.8mm≦
1.2 Packing and marking
Item
Description Class
1 Inner packing material broken. Minor
2 Carton damaged with hole over 1.5 cm in diameter. Minor
3 Carton crashed with dent over 5 cm in diameter. Minor
4 Printing of carton is illegible. Minor
5 Broken packing bag Minor
6 Spec. label's serial number not the same as carton labels. Major
7 Packing models not the same as carton. Major
8 Marking missing/wrong. Major
9 Projector missing (found none in carton). Major
10 Label on box missing or damaged. Major
