6. Optical Engine Assembly Procedure
1. Assembly Lamp module:
1.1 Baffle Lamp , Fin and Mesh Assembly
ٛ
I. Assemble “Baffle lamp” with Lamp holder and alight screw holes with holder first. (Figure
1-1)。
ٛ
II. Assemble “assembly of Fin_Mesh” on Baffle first and fasten the screw (Figure 1-2) 。
ٛ
III. Hook “Mesh” on the Lamp Holder first and fasten the screw (Figure 1-3)。
ٛ
IV. To make sure that “Assembly of Fin_Mesh” on the left side when you
face to the Baffle (Figure 1-4) 。
