Parameter Table
Following is the parameter table for both the LED and LCD Display. The last column is a convenient place to write down parameter
settings.
Quick Start Group
Control Function Group
208
APPENDIX F - PARAMETER TABLES
LED LCD Parameter Setting Range Units Default Page Setting
P1 QST 01 Motor FLA 1 – 6400 RMS Amps 10 75
P2 QST 02 Motor Service Factor 1.00 – 1.99 1.15 75
P3 QST 03 Motor Running Overload Class Off, 1 – 40 10 76
P4 QST 04 Local Source PAd: Keypad
tEr: Terminal
SEr: Serial
Terminal
77
P5 QST 05 Remote Source 78
P6 QST 06 Initial Motor Current 1 50 – 600 %FLA 100 79
P7 QST 07 Maximum Motor Current 1 100 – 800 %FLA 600 80
P8 QST 08 Ramp Time 1 0 – 300 Seconds 15 81
P9 QST 09 UTS Time / Transition Time 1 – 900 Seconds 20 82
LED LCD Parameter Setting Range Units Default Page Setting
P10 CFN 01 Start Mode
oLrP: Voltage Ramp
curr: Current Ramp
tt: TT Ramp
Pr: Power Ramp
Current
Ramp
83
P8 CFN 02 Ramp Time 1 0 – 300 Seconds 15 81
P6 CFN 03 Initial Motor Current 1 50 – 600 %FLA 100 79
P7 CFN 04 Maximum Motor Current 1 100 – 800 %FLA 600 80
P24 CFN 05 Ramp Time 2 0 – 300 Seconds 15 94
P22 CFN 06 Initial Motor Current 2 50 – 600 %FLA 100 93
P23 CFN 07 Maximum Motor Current 2 100 – 800 %FLA 600 93
P11 CFN 08 Initial Voltage/Torque/Power 1 – 100 % 25 84
P12 CFN 09 Maximum Torque/Power 10 – 325 % 105 85
P13 CFN 10 Kick Level 1 Off, 100 – 800 %FLA Off 86
P14 CFN 11 Kick Time 1 0.1 – 10.0 Seconds 1.0 86
P25 CFN 12 Kick Level 2 Off, 100 – 800 %FLA Off 94
P26 CFN 13 Kick Time 2 0.1 – 10.0 Seconds 1.0 94
P15 CFN 14 Stop Mode
CoS: Coast
SdcL: Volt Decel
TdcL: TT Decel
dcb: DC Braking
Coast 87
P16 CFN 15 Decel Begin Level 100 – 1 % 40 88
P17 CFN 16 Decel End Level 99 – 1 % 20 89
P18 CFN 17 Decel Time 1 – 180 Seconds 15 90
P19 CFN 18 DC Brake Level 10 – 100 % 25 91
P20 CFN 19 DC Brake Time 1-180 Seconds 5 92
P21 CFN 20 DC Brake Delay 0.1-3.0 Seconds 0.2 93
P27 CFN 21 Slow Speed Off, 7.1, 14.3 % Off 95
P28 CFN 22 Slow Speed Current Level 10-400 % FLA 100 95
P29 CFN 23 Slow Speed Timer Off, 1-900 Seconds 10 96
P30 CFN 24 Slow Speed Kick Level Off, 100-800 % FLA Off 96
P31 CFN 25 Slow Speed Kick Time 0.1-10.0 Seconds 1.0 97
