7 Main Menu Device Setup LB 470 Level
56925BA2 Rev. 03, 11/2017
1. Click on the field "Process value" (Fig. 92, item 3) to open the input field.
2. Enter the process value % (acc. to standard display) and confirm.
3. Click on the ″Read-In-Time″ field (Fig. 92, item 2) and specify the duration of
measurement in seconds. The higher you set the measurement time, the
more accurate the result. Click
4. Click < Ok > to accept the value.
5. Click on the button < Perform adjust now > (Fig. 92, item 1).
A new window opens (Standard Adjust Count Rate).
6. Click on the button < Start > (Fig. 92, item 5) to start the measurement.
7. Click < Ok > (Fig. 92, item 4) to accept the value.
The standard adjust was performed
When executing an Adjust, the measurement parameter set was overwritten.
If the system should be recalibrated, a Recall of the measurement parameter
set to the calibration parameter must be performed. Otherwise the Adjust will
become lost.
