3 System Description LB 470 Level
26
56925BA2 Rev. 03, 11/2017
1
2
3
4
5
6
7
8
9
10
11
Point source / shield
Mounting base with source
min / max level
Radiation field
Rod detector 1 + 2
Rod detector 1 + 2 (side view)
Measurement line (1st detector - master EVU)
Measurement line (2nd detector - slave module)
Connection master EVU - slave module
Master EVU
Slave module
Fig.
8 Schema Point source-rod detector cascaded
