Berthold Duo Xpert - Page 27

LB 470 Level 3 System Description
56925BA2 Rev. 03, 11/2017
27
1
2
3
4
5
6
7
8
Mounting base
Rod source / shield
Mounting base with source
Min/max level
Radiation field
Upper marking groove
Rod detector
Lower marking groove
Fig.
9 Schema Rod source - rod detector
1
2
3
4
5
6
7
Mounting base
Rod source / shield
Mounting base with source
Min/max level
Radiation field
Detector
Mounting base
Fig.
10 Schema Rod source - point detector
