7 Main Menu Device Setup LB 470 Level
56925BA2 Rev. 03, 11/2017
the <CU Update> (Fig. 40, item 1) button can be clicked.
4. Click on the button <CU Update> (Fig. 40, item 1).
The update is performed.
5. Measurement is interrupted.
6. Click the Button <Restart> to reboot the EVU.
Perform MU update
1. Save the current update file of the MU software on a USB storage device.
2. Connect a USB storage device to the device (Fig. 3, item 5).
3. The USB storage device is recognised by the system after a few seconds and
the <MU Update> (
Fig. 40, item 1) button can be clicked.
4. Click on the button <MU Update> (Fig. 40, item 1).
The update is performed.
5. Measurement is interrupted.
6. Click the Button <Restart> to reboot the EVU.
BERTHOLD TECHNOLOGIES recommends calibrating the current outputs when-
ever a module has been installed/replaced or if a software update has been
carried out.
