4
114
a
d
c
b
10Nm
ENGINE REASSEMBLY IN THE VEHICLE
Apply the right radiator to the frame. The opera-
tion is easier if pipes are inserted observing the
order shown in the figure.
Apply the fixing screws and tighten them to the
specified torque.
Tighten the clamps indicated.
