ENGINE DISASSEMBLY
Rimozione guarnizione 7.
Release the lock 5 and remove it.
Release the control rod 6.
Remove the gasket 7. It may be necessary to
slightly force the rubber gasket 8; place a metal
pin A between the lever and the gasket 8 and
slightly force it outwards.
