Beta RR250 - Page 22

2
20
9
A
10
ENGINE DISASSEMBLY
Remove the four collar nuts 9.
ATTENTION!
Place a clean cloth between the piston and the
crankcase to keep foreign objects or simple solid
residues from falling inside the base.
Remove the circlip 10 by gripping it with a pair of
fine nose pliers A.
Removal of piston circlip.
Removal of pin bolt.
Remove the pin bolt using a universal extractor
for pin bolts.
Remove the piston, the pin bolt and the bearing
from the connecting rod foot.
