2
33
A
A
11
ENGINE DISASSEMBLY
Remove the clutch drum together with the slip pins
followed by the spacer washer.
Using the special primary tool A (code
037.14.002.50.00), disassemble the nut that tightens
the primary gear 11 onto the crankshaft.
WARNING!
The nut must be turned clockwise.
To unscrew the nut 10, the clutch drum must
be blocked with the appropriate tool A (code
037.14.002.50.00).
Then remove the nut and relevant safety washer.
WARNING!
Do not use the pneumatic gun.
