ENGINE DISASSEMBLY
2 Ring, 3 Spring washer, 4 Pressure plate, 5 Ring, 6 Thrust bearing, 7 Clutch disc unit, 10 Slip pins, 12 Clutch drum, 13 Needle
bearing, 14 Slew bearing, 15 Spacer washer, 16 Clutch bell.
Keep the counterweight locked in place 17 using the
special tool B (code 026.14.012.50.00) and loosen
the screw.
