HardwareWood Parts
10 x 1/4 x 2” Hex Bolt
(1/4” lock washer, 1/4” at washer, 1/4” t-nut)
H2
Step 9: Front Wall Assembly
Part 2
B:Looselyattach2(2153)Postsand2(2154)FrontPoststo(2150)FrontBackGroundwith6(H2)1/4x2”Hex
Bolts(withlockwasher,atwasherandt-nut),asshowning.9.2.Noticewhere(2154)FrontPostfromStep9,
Part1isattachedandensurethat(2135)WallSupportfacestheother(2154)FrontPost.
C:Looselyattach(2114)TopFronttoeachpost,with1(H2)1/4x2”HexBolt(withlockwasher,atwasherand
t-nut)perpost.Thedistancebetween(2153)Postand(2154)FrontPostwith(2135)WallSupportmustbe16-
5/8”.(g.9.2)
2 x Post 2 x 4 x 96-1/2”
1 x Top Front 1 x 4 x 52”
1 x Front Post 2 x 2 x 94”
1 x Front Back Ground 1 x 5 x 67”
2153
2154
2150
2114
2114
2153
Fig. 9.2
1/4”lock
washer
1/4”at
washer
Noticebevelled
edgefacingup
1/4”t-nut
H2
H2
2154
2150
Noticepositionof
(2135)WallSupport
2135
16-5/8”
