HardwareWood Parts
4 x 1/4 x 3-3/4” Hex Bolt
(1/4” lock washer, 1/4” at washer, 1/4” t-nut)
2 x #8 x 1-3/4” Wood Screw
H15
1 x Front Floor 5/4 x 5 x 67”
1 x Floor Front Back 2 x 3 x 64-1/4”
2124
2120
Step 9: Front Wall Assembly
Part 3
D:Withahelperlooselyattach(2124)FrontFloorontheoutsideoftheassemblyand(2120)FloorFrontBack
ontheinsideoftheassembytoboth(2153)Postsandboth(2154)FrontPostswith1(H15)1/4x3-3/4”HexBolt
(withlockwasher,atwasherandt-nut)perpost.(g.9.3)
E: Makesureassemblyissquareandthedistancebetween(2153)Postand(2154)FrontPostwith(2135)Wall
Supportismaintainedat16-5/8”thentightenallboltsandattach(2124)FrontFloortoeach(2153)Postwith2
(S15)#8x1-3/4”WoodScrews.(g.9.3)
1/4”lock
washer
1/4”at
washer
1/4”t-nut
Fig. 9.3
S15
Outside View
2154
2120
2124
S15
2153
2153
S3
H15
H15
