Step 24: Door Wall Assembly
Part 2
6 x #6 x 5/8” Pan Screw
B:Intheopeningforthedoorbetween(2153)Postand(2154)FrontPost,measure5/8”upfromthetopof
(2150)FrontBackGroundthenattachremainingsideoftheDoorHingesontheDoorAssembyto(2153)Post
with3(S13)#6x5/8”PanScrewsperhinge.(g.24.3and24.4)
S13
Hardware
5/8”
Front
Flush
Fig. 24.4
2153
Fig. 24.3
S13
S13
2150
2154
