BD / BF / ED / FD / FED (E3.1) 02/2022 page 17/116
2.2 Triangular instrument panel
Figure 6: Triangular instrument panel
(7) Controller display
(8) Functional controller buttons
(9) USB interface
(10) Switch for Interior lighting (option)
2.3 Main power switch ED, FD, FED 720
The chambers ED, FD, FED size 720 are equipped with a main power switch located on the chamber rear.
Off On
Figure 7: Main power switch on the chamber rear
(10)
(8)
(7)
(9)
