4.2 Electrical connection
The chambers are supplied ready for connection and.
The chambers ED720 / FD720 / FED720 / FED720UL come with a fixed power connection cable of at least
1800 mm / 70.87 in in length. The other chambers come with an IEC connector plug.
Model
Power plug /
power
cable
Nominal voltage +/- 10% at the
indicated power frequency
Current
type
Chamber
fuse
BD056-230V
BF056-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
ED056-230V
FD056-230V
FED056-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
BD115-230V
BF115-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
ED115-230V
FD115-230V
FED115-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 6,3 A
BD260-230V
BF260-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 8,0 A
ED260-230V
FD260-230V
FED260-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 12,5 A
BD720-230V
BF720-230V
Grounded plug
230 V at 50 Hz
230 V at 60 Hz
1N~ 12,5 A
ED720-400V
FD720-400V
FED720-400V
Grounded plug
400 V at 50 Hz
400 V at 60 Hz
3N~ ---
BD056UL-120V
BF056UL-120V
NEMA 5-15P
SJT 14AWG*3C
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
ED056UL-120V
FD056UL-120V
FED056UL-120V
NEMA 5-15P
SJT 14AWG*3C
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
BD115UL-120V
BF115UL-120V
NEMA 5-15P
SJT 14AWG*3C
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
ED115UL-120V
FD115UL-120V
FD115UL-120V
NEMA 5-15P
SJT 14AWG*3C
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
BD260UL-120V
BF260UL-120V
NEMA 5-15P
SJT 12AWG*3C
120 V at 50 Hz
120 V at 60 Hz
1N~ 12,5 A
ED260UL-240V
FD260UL-240V
FED260UL-240V
NEMA 6-20P
SJT 12AWG*3C
240 V at 50 Hz
240 V at 60 Hz
2~ ---
BD720UL-240V
BF720UL-240V
NEMA 6-20P
SJT 12AWG*3C
240 V at 50 Hz
240 V at 60 Hz
2~ ---
FED720UL-208V NEMA L21-20P
208 V at 50 Hz
208 V at 60 Hz
3N~ ---
