BD / BF / ED / FD / FED (E3.1) 02/2022 page 76/116
Chamber size
BD 56
BD 115
BD 260
BD 720
Electrical data (continued)
Power plug of the power cable
Grounded plug
Chamber fuse (external) 5x20 mm /
250V / time-lag (T)
A 6.3 6.3 8.0 12.5
Overtemperature protective device
class 1
°C 120 120 120 120
Installation category acc. to IEC 61010-1
II
II
II
II
Pollution degree acc. to IEC 61010-1
2
2
2
2
Different electrical data for BD-UL constructed for the USA and Canada
(model versions BD056UL-120V, BD115UL-120V, BD260UL-120V, BD720UL-240V)
Nominal
voltage
(+/-10%)
at 50 Hz power frequency V 120 120 120 240
at 60 Hz power frequency V 120 120 120 240
Current type
1N~
1N~
1N~
2~
Nominal power
kW
0,30
0,35
0,95
1,75
Power plug of the power cable
NEMA
5-15P
5-15P
5-15P
6-20P
Chamber fuse (external)
5x20 mm / 250V / time-lag (T)
A 12.5 12.5 12.5 ---
Miniature circuit breaker (internal)
A
---
---
---
16
Environment-specific data
Energy consumption at 37 °C /
98.6 °F
Wh/h 25 25 40 78
All technical data is specified for unloaded chambers with standard equipment at an ambient temperature
of +22 °C +/- 3 °C / 71.6 °F +/- 5.4 °F and a power supply voltage fluctuation of +/-10%. Technical data is
determined in accordance to BINDER Factory Standard Part 2:2015 and DIN 12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right to
change technical specifications at any time.
If the chamber is fully loaded, the specified heating up times may vary according to the load.
With option interior socket: If electrical devices are connected and operating inside the cham-
ber, the temperature range may be modified due to heat emission.
16.5 BF technical data
Chamber size
BF 56
BF 115
BF 260
BF 720
Exterior dimensions
Width, net
mm / inch
560 / 22.01
710 / 27.95
815 / 32.09
1165 / 45.87
Height, gross (incl. feet)
mm / inch
625 / 24.60
735 / 28.94
965 / 37.99
1590 / 62.60
Depth, net
mm / inch
565 / 22.24
605 / 23.82
760 / 29.92
816 / 32.13
Depth, gross (incl. door handle and
exhaust duct)
mm / inch 640 / 25.20 680 / 26.77 815 / 32.09 870 / 34.25
Wall clearance rear (minimum)
mm / inch
160 / 6.30
160 / 6.30
160 / 6.30
160 / 6.30
Wall clearance side (minimum)
mm / inch
100 / 3.94
100 / 3.94
100 / 3.94
100 / 3.94
Exhaust duct, outer diameter
mm / inch
52 / 2.05
52 / 2.05
52 / 2.05
52 / 2.05
Doors
Number of doors
1
1
1
2
Number of inner glass doors
1
1
1
2
Interior dimensions
Width
mm / inch
400 / 15.75
550 / 21.65
650 / 25.59
1000 / 39.37
Height
mm / inch
440 / 17.32
550 / 21.65
780 / 30.71
1300 / 51.18
Depth
mm / inch
340 / 13.39
380 / 14.96
510 / 20.08
560 / 22.05
