Binder BF 56 - Displaying the Effective Ramp Set-Point and Changing the Target Ramp Set-Point

BD / BF / ED / FD / FED (E3.1) 02/2022 page 54/116
9.3 Displaying the effective ramp set-point and changing the target ramp set-
point
From Normal display showing the actual temperature (example: 27 °C), the
gradient (example: 1) and the target ramp set-point (example: 40 °C)
to the display of the effective ramp set-point
The effective ramp set-point is displayed
Press OK to set the target ramp set-point
The target ramp set-point value flashes.
Enter the target ramp set-point
and confirm with OK.
The effective ramp set-point is displayed
2x
Back to Normal display.
Normal display showing the actual temperature, the gradient and the modi-
fied target ramp set-point (example: 50 °C)
