Binder BF 56 - FED technical data

BD / BF / ED / FD / FED (E3.1) 02/2022 page 81/116
Chamber size
FD 56
FD 115
FD 260
FD 720
Electrical data (continued)
(model versions FD056-230V, FD115-230V, FD260-230V, FD720-400V)
Current type
1N~
1N~
1N~
3N~
Nominal power
kW
1.10
1.30
2.30
4.50
Power plug of the power cable
Grounded plug
Chamber fuse (external)
5x20 mm / 250V / time-lag (T)
A 6.3 6.3 12.5 ---
Miniature circuit breaker (internal)
A
---
---
---
16
Overtemperature protective device
class 1
°C 330 350 330 330
Installation category acc. to IEC 61010-1
II
II
II
II
Pollution degree acc. to IEC 61010-1
2
2
2
2
Different electrical data for FD-UL constructed for the USA and Canada
(model versions FD056UL-120V, FD115UL-120V, FD260UL-240V)
Nominal
voltage
(+/-10%)
at 50 Hz power frequency V 120 120 240 ---
at 60 Hz power frequency V 120 120 240 ---
Current type
1N~
1N~
2~
---
Nominal power
kW
1.20
1.40
2.50
---
Power plug of the power cable
NEMA
5-15P
5-15P
6-20P
---
Chamber fuse (external)
5x20 mm / 250V / time-lag (T)
A 12.5 12.5 --- ---
Miniature circuit breaker (combina-
tion element)
A --- --- 16 ---
Environment-specific data
Noise level (mean value)
dB (A)
43
43
43
43
Energy consumption at 150 °C /
302 °F
Wh/h
300 340 420 800
All technical data is specified for unloaded chambers with standard equipment at an ambient temperature
of +22 °C +/- 3 °C / 71.6 °F +/- 5.4 °F and a power supply voltage fluctuation of +/-10%. Technical data is
determined in accordance to BINDER Factory Standard Part 2:2015 and DIN 12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right to
change technical specifications at any time.
If the chamber is fully loaded, the specified heating up times may vary according to the load.
16.8 FED technical data
Chamber size
FED 56
FED 115
FED 260
FED 720
Exterior dimensions
Width, net
mm / inch
560 / 22.01
710 / 27.95
815 / 32.09
1165 / 45.87
Height, gross (incl. feet)
mm / inch
625 / 24.60
735 / 28.94
965 / 37.99
1590 / 62.60
Depth, net
mm / inch
565 / 22.24
605 / 23.82
760 / 29.92
816 / 32.13
Depth, gross (incl. door handle and
exhaust duct)
mm / inch 640 / 25.20 680 / 26.77 815 / 32.09 870 / 34.25
Wall clearance rear (minimum)
mm / inch
160 / 6.30
160 / 6.30
160 / 6.30
160 / 6.30
Wall clearance side (minimum)
mm / inch
100 / 3.94
100 / 3.94
100 / 3.94
100 / 3.94
Exhaust duct, outer diameter
mm / inch
52 / 2.05
52 / 2.05
52 / 2.05
52 / 2.05
Doors
Number of door(s)
1
1
1
2
