BD / BF / ED / FD / FED (E3.1) 02/2022 page 80/116
16.7 FD technical data
Chamber size
FD 56
FD 115
FD 260
FD 720
Exterior dimensions
Width, net
mm / inch
560 / 22.01
710 / 27.95
815 / 32.09
1165 / 45.87
Height, gross (incl. feet)
mm / inch
625 / 24.60
735 / 28.94
965 / 37.99
1590 / 62.60
Depth, net
mm / inch
565 / 22.24
605 / 23.82
760 / 29.92
816 / 32.13
Depth, gross (incl. door handle and
exhaust duct)
mm / inch 640 / 25.20 680 / 26.77 815 / 32.09 870 / 34.25
Wall clearance rear (minimum)
mm / inch
160 / 6.30
160 / 6.30
160 / 6.30
160 / 6.30
Wall clearance side (minimum)
mm / inch
100 / 3.94
100 / 3.94
100 / 3.94
100 / 3.94
Exhaust duct, outer diameter
mm / inch
52 / 2.05
52 / 2.05
52 / 2.05
52 / 2.05
Doors
Number of door(s)
1
1
1
2
Interior dimensions
Width
mm / inch
400 / 15.75
550 / 21.65
650 / 25.59
1000 / 39.37
Height
mm / inch
440 / 17.32
550 / 21.65
780 / 30.71
1300 / 51.18
Depth
mm / inch
345 / 13.58
385 / 15.16
510 / 20.08
570 / 22.44
Interior volume
l / cu.ft.
60 / 2.12
116 / 4.10
257 / 9.08
741 / 26.17
Steam space volume
l / cu.ft.
67 / 2.37
127 / 4.49
279 / 9.85
791 / 27.93
Racks
Quantity of racks (regular)
2
2
2
2
Quantity of racks (max.)
4
5
8
16
Max. load per rack (standard rack)
Kg / lbs
30 / 66
30 / 66
44 / 88
45 / 99
Max. load per rack (optional perfo-
rated shelf)
Kg / lbs 35 / 77 35 / 77 35 / 77 35 / 77
Max. load per rack (optional heavy
load rack)
Kg / lbs 50 / 110 70 / 154 80 / 176 70 / 154
Permitted total load
Kg / lbs
70 / 154
150 / 330
270 / 595
315 / 694
Weight
Weight (empty)
Kg / lbs
39 / 86
54 / 119
85 / 187
166 / 366
Temperature data
Temperature
range
from … degrees
above ambient
°C / °F 10 / 18 10 / 18 10 / 18 12 / 21.6
up to
°C / °F
300 / 572
300 / 572
300 / 572
300 / 572
Temperature fluctuation at 150 °C /
302 °F
± K 0.3 0.3 0.5 0.6
Temperature uniformity (variation)
at 150 °C / 302 °F
± K 1.7 1.7 1.9 2.5
Heating up time to 150 °C / 302 °F
minutes
15
19
20
25
Recovery time after door was
opened for 30 sec at 150 °C /
302 °F
minutes 4 5 6 6
Ventilation data
Air change
at 100 °C / 212 °F
x/h
80
32
9
5
Electrical data
(model versions FD056-230V, FD115-230V, FD260-230V, FD720-400V)
System of protection acc. to EN
60529
IP 20 20 20 20
Nominal
voltage
(+/-10%)
at 50 Hz power frequency V 230 230 230 400
at 60 Hz power frequency V 230 230 230 400
