BD / BF / ED / FD / FED (E3.1) 02/2022 page 79/116
Chamber size
ED 56
ED 115
ED 260
ED 720
Temperature data
Temperature
range
from … degrees
above ambient
°C / °F 5 / 9 5 / 9 5 / 9 5 / 9
up to
°C / °F
300 / 572
300 / 572
300 / 572
300 / 572
Temperature fluctuation at 150 °C /
302 °F
± K 0.5 0.4 1.0 0.8
Temperature uniformity (variation)
at 150 °C / 302 °F
± K 2.5 2.0 2.0 3,2
Heating up time to 150 °C / 302 °F
minutes
45
45
55
85
Recovery time after door was
opened for 30 sec at 150 °C /
302 °F
minutes 35 16 20 25
Electrical data
(model versions ED056-230V, ED115-230V, ED260-230V, ED720-400V)
IP system of protection acc. to EN
60529
IP 20 20 20 20
Nominal
voltage
(+/-10%)
at 50 Hz power frequency V 230 230 230 400
at 60 Hz power frequency V 230 230 230 400
Current type
1N~
1N~
1N~
3N~
Nominal power
kW
1.05
1.25
2.25
4.10
Power plug of the power cable
Grounded plug
Chamber fuse (external)
5x20 mm / 250V / time-lag (T)
A 6.3 6.3 12.5 ---
Miniature circuit breaker (internal)
A
---
---
---
16
Overtemperature protective device
class 1
°C 330 330 330 330
Installation category acc. to IEC 61010-1
II
II
II
II
Pollution degree acc. to IEC 61010-1
2
2
2
2
Different electrical data for ED-UL constructed for the USA and Canada
(model versions ED056UL-120V, ED115UL-120V, ED260UL-240V)
Nominal
voltage
(+/-10%)
at 50 Hz power frequency V 120 120 240 ---
at 60 Hz power frequency V 120 120 240 ---
Current type
1N~
1N~
2~
---
Power plug of the power cable
NEMA
5-15P
5-15P
6-20P
---
Nominal power
kW
1.15
1.35
2.45
---
Chamber fuse (external)
5x20 mm / 250V / time-lag (T)
A 12.5 12.5 --- ---
Miniature circuit breaker
(combination element, external)
A --- --- 16 ---
Environment-specific data
Energy consumption at 150 °C /
302 °F
Wh/h 180 250 370 700
All technical data is specified for unloaded chambers with standard equipment at an ambient temperature
of +22 °C +/- 3 °C / 71.6 °F +/- 5.4 °F and a power supply voltage fluctuation of +/-10%. Technical data is
determined in accordance to BINDER Factory Standard Part 2:2015 and DIN 12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right to
change technical specifications at any time.
If the chamber is fully loaded, the specified heating up times may vary according to the load.
