BD / BF / ED / FD / FED (E3.1) 02/2022 page 50/116
The minute value flashes.
Enter the minutes of the timer run-time (0 up to 59)
confirm with OK
and go on to enter the temperature set-point
The temperature set-point flashes.
Enter the temperature set-point,
confirm with OK and go on to enter the fan speed set-point valid for the time af-
ter the timer has expired
The current fan speed set-point is shown
Enter the fan speed in steps of 10 % -
0 % and 40 % up to 100 %
and confirm with OK.
The timer function “Delayed On” is activated
2x
Back to Normal display.
Normal display during timer operation with timer function “Delayed On”
The Timer run-time until turning on the heating is running.
Timer function “Delayed On”.
The heating is off, temperature approximates ambient temperature.
Normal display after the timer has expired:
The timer has expired. The time function is off.
The heating is active to equilibrate the temperature set-point.
The fan operates with the selected fan speed.
