Entering the safety controller setpoint
Fixed value
08.03.2013 05:05:06
Submenu “Safety controller”
(view with standard unit equipment)
Select “Setpoint”
and press the operating button.
..\ Safety controller
Mode
Setpoint
Show settings
Close Home
or
Fixed value
08.03.2013 05:05:06
Submenu “Safety controller”
(view with optional unit equipment)
Select “Overtemperature“
and press the operating button.
..\ Safety controller
Mode
Overtemperature
Undertemperature
Show settings
Close Home
In case of a temperature safety device class 3.1 combined with optional unit equipment, the
safety controller setpoint is indicated as “Overtemperature”. In this case an additional
parameter “Undertemperature” is shown. This latter has no function; if you select it, the
message “Setpoints not available” appears.
You can also access this submenu to directly enter the safety controller setpoint via
Quick menu > safety controller setpoint
Fixed value
08.03.2013 05:05:06
Entry menu “Safety controller setpoint”.
Enter the desired value with the operating button
and press the operating button to confirm.
Press the “Ok” button to confirm.
..\ Safety controller setpoint
4
5.0
[°C]
4
End Ok 0 1 2 3 5 6 7 8 9 Del Ins
Close Ok Home
Go one level back with the “Close” button or back to the initial view with “Home”.
