KT (E6.1) 07/2015 Page 30/138
7. Configuration of optional equipment
The “Optional equipment” menu item is visible only with optional unit equipment.
To access the selection menu, go to Menu > Optional equipment
Fixed value
08.03.2013 05:05:06
Submenu “Optional equipment”.
Select the desired function
and press the operating button.
..\ Optional equipment
Door heating
Interior socket
Zero-voltage relay control outputs
Functional test – alarm output
Object temperature display
Close Home
7.1 Setting the optional door heating
For chambers equipped with an optional door heating, you can turn it on and off via the controller. You
can also set the door heating offset to the temperature set-point.
To access the door heating setting menu, go to Menu > Optional equipment > Door heating
Fixed value
08.03.2013 05:05:06
Submenu “Door heating”.
Select the desired function
and press the operating button.
“Door heating On/Off” = Turning on or off the door
heating
“Door heating Offset” = Temperature difference to
the entered setpoint
..\ Door heating On/Off
Door heating On/Off
Door heating Offset
Close Home
Turning on or off the door heating:
Fixed value
08.03.2013 05:05:06
Submenu “Door heating On/Off ”.
The current setting is indicated.
To change the setting,
press the operating button.
The modified setting is displayed.
“Door heating: On” = door heating turned on
“Door heating: Off” = door heating turned off
..\ Door heating On/Off
Door heating: Off
Close Home
