Overview of the current settings
You can check the current settings of the safety controller:
Fixed value
08.03.2013 05:05:06
Submenu “Safety controller”
Select “Show safety controller settings”
and press the operating button.
..\ Safety controller
Mode
Over temperature
Under temperature
Show settings
Close Home
The overview display shows the set-points and actual values of the main temperature controller and the
safety controller and indicates the safety controller mode.
Fixed value
08.03.2013 05:05:06
Overview display with safety controller mode “Limit”
(example values)
Setpoint
Actual
Chamber temperature [°C]
37.0 37.6
Safety controller mode
Limit (absolute)
Overtemperature [°C]
40.0 37.6
Undertemperature [°C]
32.0
Close Home
Fixed value
08.03.2013 05:05:06
Overview display with safety controller mode
“Offset” (example values)
Setpoint
Actual
Chamber temperature [°C]
37.0
37.6
Safety controller mode
Offset (relative)
Overtemperature [°C]
3.0 37.6
Undertemperature [°C]
5.0
Close Home
Go back to the initial view with “Home”.
