Bitzer ACP Link - General Safety References; 3 Required Special Tools

6 CT-600-2
NOTICE
Safety reference to avoid situations which may result in damage to a device or its equipment.
CAUTION
Safety reference to avoid a potentially hazardous situation which may result in minor or moderate
injury.
WARNING
Safety reference to avoid a potentially hazardous situation which could result in death or serious injury.
DANGER
Safety reference to avoid an imminently hazardous situation which may result in death or serious injury.
2.4 General safety references
The HMI Human Machine Interface on the ACP LINK may only be operated when the main ACP LINK panel,
CM-SW-01/CM-IO modules and starter panel are closed. In case it is necessary to open one of the panels or
modules or Motor Connection boxes for software updates or work on the electric or electronic components for
installation or service, then this may only be done by authorized staff.
When working on the electrical system and the ACP LINK panel
DANGER
Life-threatening voltages inside the electrical panel housing!
Contact can cause severe injury or death.
Never open electrical panel housing during operation!
Switch off the main switch and secure it against being switched on again.
Before switching on again, close the electrical panel housing.
When welding on the unit or plant
NOTICE
Risk of damage to electronic components.
Before welding on the ACP unit or connected piping and equipment: switch off the main switch and secure
it against being switched on again.
When welding on the ACP unit or connected piping and equipment: make sure that the welding ground
lead is connected properly and close to the welding spot.
3 Required special tools
1 SD-card recommended brand (Scandisk, Kingston, Schneider), preferred size 4 – 32 Gb.
2 USB-stick (USB type 1 or 2), recommended brand (Scandisk, Kingston), preferred size 4 Gb.
3 PC with SD-card slot and latest version of BEST SOFTWARE installed.
4 BEST interface converter (BITZER part no. 34431402).
5 HB Products programming cable (HB Products part no. HBxC-USB) and latest version of HB Tool
software (only for optional economizer system).
!
!
!
!
