80 CT-600-2
13 Parameter and timer overview
13.1 Overview of parameters in ACP LINK PLC/HMI
Communication parameters
Communication port Setting Default value
PLC name NodeName MAIN_CONTROLLER1
For subsequent units on same network:
MAIN_CONTROLLER2, MAIN_CONTROLLER3 ..
PLC Ethernet 1 IP 192.168.1.100
(Ethernet network) Subnet 255.255.255.0
Gateway 192.168.1.1
PLC Ethernet 2 IP 0.0.0.0
(Device network) Subnet 0.0.0.0
Gateway 0.0.0.0
PLC Serial RS485 Node/Modbus address 0
Data bit 8
Stop bit 1
Parity Even
Baudrate 19200
HMI Ethernet 1 IP 192.168.1.101
Subnet 255.255.255.0
Gateway 192.168.1.1
HMI Ethernet 2 IP 1.1.1.2
Subnet 255.255.255.0
Gateway 1.1.1.1
Regulation mode parameters
No. Description Page on HMI Default
value
Default
unit
0.1 Regulation Mode CTRL Stopped
0.2 Cap. Set. (Manual mode) CTRL 0
0.3 Start priority 1, 2, 3 CTRL 0
0.4 Enable/disable module (1 - 3, 10, 11, 12) Service\Commu
nication Setup
Disabled
