86 CT-600-2
No. Description Param. page
on HMI
Default
value (s)
26 Alarm delay LP waiting for HP Timer 3 600
27 Alarm delay high oil sys. temp. Timer 3 5
28 Alarm/Warning delay start perm. Timer 3 60
29 Alarm delay external alarm Timer 3 5
30 Motor 1, 2, 3 feedback low time Timer 4 - 1, 2, 3 20
31 Compressor 1, 2, 3 feedback low time Timer 4 - 1, 2, 3 20
32 Compressor 1, 2, 3 start unload time Timer 4 - 1, 2, 3 60
33 Compressor 1, 2, 3 stop unload time Timer 4 - 1, 2, 3 300
34 Motor 1, 2, 3 current high warning time Timer 4 - 1, 2, 3 3600
35 Compressor 1, 2, 3 start to start time Timer 4 - 1, 2, 3 600
36 Compressor 1, 2, 3 warning delay oil filter Timer 4 - 1, 2, 3 60
13.3 Overview of parameters in CM-SW-01 – compressors
Only parameters different from default are shown here. Further information see ST-150.
NOTICE
The table below contains two columns for user settings. One column shows the settings when using the
motor start functions “frequency inverter” or “soft starter” on the CM-SW-01 in the section “MotorStart”.
These operating modes require the use of the run feedback signal from the frequency inverter or soft
starter to the CM-SW-01. If this mode is not used, or if this signal is not connected, then the motor start
function “DOL” must be used instead. See also section 7.1 for difference in electrical connections.
Parameter Section User Setting
COM 1 address COM 1 1 (compressor 1)
2 (compressor 2)
3 (compressor 3)
Enable automatic slider calibration SliderCal No
Compressor type selection Config Type as on name plate
Discharge pressure selection Config PE 5000-5093-2: 0.00-32.00 bar(g)
PE 5000-5094-3: 0.00-34.47 bar(g)
(acc. to actual type used)
Suction presure selection Config PE 5000-5093-1: -1.00-9.00 bar(g)
PE 5000-5094-4: -1.00-12.79 bar(g)
(acc. to actual type used)
Mains supply voltage specification (single
phase)
Config 230 / 115 (depending on region)
Setpoint control characteristic Config 0 .. Max
Compressor stop capacity limit Config 0.00
!
!
