15 Modbus TCP/IP signal list
See section 9.10 and 13.1 for Ethernet connection setup and parameters.
NOTICE
The tables in this section show the Modbus addresses as 16-bit words (%MW). When reading a double
word (%MD), the address must be divided by two. Example (see first line in section 15.3): “number of
enabled compressors” can be read in address %MD20016, which corresponds to %MW40032
- %MW40033.
15.1 List of alarms and addresses on Modbus TCP/IP
See table in section 14.1 for complete list of alarm and alarm numbers.
Address Bit Alarm No. Alarm signal
%MW40000 %MW40000:X0 0 Not used
%MW40000:X1 1 Suction pressure low
%MW40000:X2 2 Suction pressure high
%MW40000:X3 3 Discharge pressure low
%MW40000:X4 4 Discharge pressure high
%MW40000:X5 5 Pressure ratio high
%MW40000:X6 6 Pressure difference low
%MW40000:X7 7 Lubricating pressure low
%MW40000:X8 8 Oil system pressure drop high
%MW40000:X9 9 Main oil filter pressure drop high
%MW40000:X10 10 Suction superheat low
%MW40000:X11 11 Suction superheat high
%MW40000:X12 12 Suction pressure sensor difference high
%MW40000:X13 13 Suction pressure sensor error
%MW40000:X14 14 Discharge pressure sensor difference high
%MW40000:X15 15 Oil temperature low
%MW40001 %MW40001:X0 16 Oil temperature high
... ... ...
%MW40001:X15 31 External input external alarm
%MW40002 %MW40002:X0 32 Not used
... ... ...
!
!
