13.4 Overview of parameters in CM-IO – oil and economizer system
Only parameters different from default are shown here. Further information see ST-150.
Parameter Section User Setting
COM 1 address COM 1 Oil system: 11
Eco system: 12
Compressor type selection Config None
Discharge pressure selection Config PE 5000-5093-2: 0.00-32.00 bar(g)
PE 5000-5094-3: 0.00-34.47 bar(g)
(acc. to actual type used)
Suction pressure selection Config PE 5000-5093-2: 0.00-32.00 bar(g)
PE 5000-5094-3: 0.00-34.47 bar(g)
(acc. to actual type used)
Dedicated OEM functionality selection Config Remote IO
Mains supply voltage specification (single
phase)
Config 230 / 115 (depending on region)
Compressor serial number (actual) CompInfo Number as on name plate for oil
separator or economizer
Customer, Location CompInfo Site description
System name, Compressor number CompInfo ACP type designation and oil
separator or economizer type
Serial Control Source SerCtrlCfg COM1 (MODBUS)
Serial Communication Timeout Function SerCtrlCfg Fault
Serial Communication Timeout SerCtrlCfg 15
13.5 Overview of parameters in M172 – electrical panel I/O
List of parameters set in Settings page for electrical panel IO-module (M172). Actual setup may be different,
according to sensor types used.
Communication parameters
Communication port Setting Default value
Ethernet IP 10.4.156.21
Subnet 255.255.255.0
Gateway 10.4.156.1
RS485-1 & RS 485-2 Node/Modbus address 10
Data bit 8
Stop bit 1
Parity Even
Baudrate 19200
