90 CT-600-2
AI and AO parameters
3
No. Signal Default type Calib.AI ScaleMinAi – ScaleMaxAi
AI1 Current motor 1 0-10V 0 0-1000
AI2 Current motor 2 0-10V 0 0-1000
AI3 Current motor 3 0-10V 0 0-1000
AI4 Remote capacity setpoint 2 0-10V 0 0-100
AI5 Suction temperature PT1000 0 0-1000
AI6 Discharge temperature PT1000 0 0-1000
AI7 Suction Pressure AKS 33: 4-20mA
PE 5000: 0-5V
rat.
0 AKS 33: 0-1000
PE 5000-5093-1: 0-1000
PE 5000-5094-4: 0-1379
(signal out in 0.01 bara)
AI8 Discharge Pressure AKS 33: 4-20mA
PE 5000: 0-5V
rat.
0 AKS 33: 100-2600
PE 5000-5093-2: 100-3300
PE 5000-5094-3: 100-3447
(signal out in 0.01 bara)
AI9 Process temperature PT1000 0 0-1000
AI10 Auxilary temperature PT1000 0 0-1000
AI11 Remote capacity setpoint 1 0-10V 0 0-100
AI12 Remote capacity setpoint 3 /
External Capacity Limiter in
Auto Mode
0-10V 0 0-100
AO1 Speed setpoint motor 1 0-10V
AO2 Speed setpoint motor 2 0-10V
AO3 Speed setpoint motor 3 0-10V
3
Analog inputs must be of equal type in pairs, e.g. AI1 and AI2 both 0-10V or both 4-20mA, etc.
