64 CT-600-2
Analog outputs
See sections 9.6 and 13.5 for more information on configuration of the analog outputs.
AO no. CN Rating Connection Comment
AO 1 CN2 0-10V VSD speed
setpoint 1
Signal from ACP LINK to electrical panel with speed set
point for motor/drive on compressor no. 1. Only required
for operation with variable speed. Must be connected to
analog input for speed set point on the variable speed
drive.
AO 2 CN2 0-10V VSD speed
setpoint 2
Same as AO1 for motor/drive on compressor no. 2.
AO 3 CN2 0-10V VSD speed
setpoint 3
Same as AO1 for motor/drive on compressor no. 3.
AO 4 CN2 0-10V Not used
AO 5 CN11 0-10V Not used
AO 6 CN11 0-10V Not used
