Chapter 2: Overview
Table 2-1. Front-panel components.
Number in
Figure 2-1
Component Status Description
1 Power LED Off Power is off.
On Power is on.
2 Wireless LED Off The wireless function is disabled.
On The wireless function is enabled. The router is working on 2.4 GHz or 5 GHz or
both radio bands.
3 Ethernet LED Off No device is connected to the LAN ports.
On At least one device has connected to the LAN ports.
4 Internet LED Off The Internet connection is not available.
On The network is available with a successful Internet connection.
5 USB LED Off No storage device is plugged into the USB port.
Flashing A plugged-in storage device is being recognized.
On The storage device has been successfully recognized.
6 WPS LED Slow Flash A wireless device is connecting to the network by WPS function. This process
will last in the first 2 minutes.
On A wireless device has been successfully added to the network by WPS function.
Quick Flash A wireless device failed to be added to the network by WPS function.
NOTES:
1. After a device is successfully added to the network by WPS function, the WPS LED will keep on for about five minutes and then
turn off.
2. The router is set to work concurrently in 2.4 GHz and 5 GHz by default. To choose the working frequency, go to 5.5 Dual Band
Selection.
